PM100RL1B060

You Pay $216.30
7 In Stock!
Quantity Discounts:
10+ 196.35
Amps: 100
Volts: 600

Mitsubishi Electric Intelligent Power Module

Mitsubishi Electric Intelligent Power Module

FEATURES
Inverter + Drive & Protection IC

a) Adopting new 5th generation Full-Gate CSTBTTM chip
b) The over-temperature protection which detects the chip surface temperature of CSTBTTM is adopted.
c) Error output signal is possible from all each protection upper and lower arm of IPM.
d) Compatible L-series package.

• 3φ 100A, 600V Current-sense and temperature sense IGBT type inverter
• Monolithic gate drive & protection logic
• Detection, protection & status indication circuits for, short circuit, over-temperature & under-voltage (P-FO available from upper arm devices)
• UL Recognized

Application
General purpose inverter, servo drives and other motor controls

  • Amps : 100
  • Volts : 600
