LV 20-P

You Pay $38.15
15 In Stock!
Quantity Discounts:
10+ 29.40
100+ 23.55

Current transducer

For the electronic measurement of currents: DC, AC, pulsed, mixed... with galvanic isolation between primary circuit (high power) and secondary circuit (electronic circuit).

Closed loop (compensated) current transducer using the hall effect
Isolated plastic case recognized according to UL 94-V0
Excellent accuracy
Very good linearity
Low thermal drift
Low response time
High bandwidth
High immunity to external interference
Low disturbance in common mode
AC variable speed drives and servo motor drives
Static converters for DC motor drives
Battery supplied applications
Uninterruptible Power Supplies (UPS)
Power supplies for welding applications
