5STP 50Q1800

You Pay $1,981.00
6 In Stock!
Amps: 6100
Volts: 1800

Phase Control Thyristor 5STP 50Q1800

Phase Control Thyristor 5STP 50Q1800

Features
Patented free-floating silicon technology
Low on-state and switching losses
Designed for traction, energy and industrial applications
Optimum power handling capability
Interdigitated amplifying gate

IT(RMS) = 9600 A
ITSM = 94.0·103 A
VT0 = 0.9 V
rT = 0.05 m

  • Volts : 1800
  • Amps : 6100
