HAB 80-S

Features

Open Loop transducer using the Hall effect sensor
 Low voltage application
 Unipolar + 5 V DC power supply
 Primary current measuring range ± 80 A
 Maximum RMS primary current limited by the busbar, the magnetic core or the ASIC temperature T° < + 150°C
Operating temperature range: - 40°C < T° < + 125°C.

Advantages
Good accuracy for high and low current range
 Good linearity
 Low thermal offset drift
 Low thermal gain drift
 Hermetic package.
