AP 50 B10

You Pay $121.80
Product out of stock
Quantity Discounts:
5+ 115.70
10+ 112.05

Split-core transducer for the electronic measurement of AC sinusoidal waveform currents, with galvanic separation between the primary circuit and secondary circuit. Switch selectable measuring ranges and rms -5 V and 0-10 V switch selectable voltage output.

Features
Rms output (Average)
Split-core type
0-5 V DC and 010 V DC switch selectable voltage output
DIN rail or Panel mounting
Switch selectable measuring ranges
Insulating plastic case recognized according to UL 94-V0
Advantages
Large aperture for cable up to 18mm
High insulation between primary and secondary circuits
Eliminates insertion loss
Easy installation
Applications
Automation Systems:
Analog current reading for remote monitoring (e.g. motor) and software alarms
Panel Meters:
Simple connection to power consumption displays
